Application Features of Sesame Sieving Machine

1. All stainless steel material can ensure the food safety of sesame seeds.

2. A net-cleaning pinball can be set under the screen to avoid blockage of sesame particles by hitting the screen.

3. It can be used with dust removal equipment, iron removal equipment, and air-cooling device for sesame screening, and can flexibly handle dusty, iron filings impurities, and high-temperature cooked sesame screening.

4. The screen can be changed arbitrarily according to the user's requirements. The meshes commonly used in the sesame industry are 10/14/16/18 mesh.

5. It can be used with screw feeding, silo, grinding equipment, etc. to form a complete sesame production line, and the impurities in sesame can be automatically discharged.


Application of Sesame Sieving Machine

Sesame Sieving Machine is a small and medium-sized grain vibrating screening machine, which is used to remove leaves, chaff, dust and shriveled grains and other sundries in sesame or other grain crops. The removal rate of organic matter reaches 90%, and the removal rate of inorganic matter reaches 92%, and the screen can be replaced arbitrarily according to user requirements, not only sesame, but also suitable for screening and removing impurities of different materials, most of which are single-layer design.

Application of Sesame Sieving Machine in Sesame Oil Squeezing or Sesame Paste Processing

Extracting sesame oil or making sesame paste usually includes the following processes:

A. The harvested sesame is screened and washed with water, the purpose is to remove small stones, dust, etc. in low-quality sesame and mixed sesame

B. The sesame seeds that have been cleaned of impurities are put into the frying pan for frying

C. Fry to a suitable state, use cold water or other methods to rapidly cool the sesame from heat to loosen the structure and prevent burnt

D. to cool down further

E. Carry out oil extraction or sauce making

Sesame Sieving Machine is mainly used in process A of sesame oil extraction or sesame paste processing to screen sesame to ensure that 99% of impurities are removed before processing.

During the impurity removal process of sesame, it can be used with dust removal equipment, iron remover and other equipment to remove too small dust and possible metal shavings in sesame, so as to ensure the food safety of sesame products processed and meet the edible standards.

Application video demonstration of Sesame Sieving Machine

Model parameters of Sesame Sieving Machine

Model Layer Screening Area
(mm)
Mesh Size
(mesh)
Particle Size
(mm)
Capacity
(t/h)
Power
(kw)
Vibration Direction Angle
(°)
Screen Inclination
(°)
Dual Amplitude
DZSF-520 1-6 layers 500*2000 2-400 0.074-10 ≤3 0.37×2 45-60 0-7 3-4.5
DZSF-525 500*2500 ≤5 0.37×2
DZSF-612 600*1200 ≤8 0.37×2
DZSF-1020 1000*2000 ≤12 0.75×2
DZSF-1025 1000*2500 ≤16 0.75×2
DZSF-1030 1000*3000 ≤20 1.1×2
DZSF-1224 1200*2400 ≤23 1.5×2
DZSF-1525 1500*2500 ≤28 1.5×2
DZSF-1530 1500*3000 ≤32 2.2×2

Structure of Sesame Sieving Machine

Sesame Sieving Machine is mainly composed of feed inlet, dust cover, screen box, screen mesh, discharge outlet, vibration motor, force guide plate, shock absorbing spring and base from top to bottom.

Screen: It is mainly used for screening materials. The aperture size of the screen ranges from 2 mesh to 400 mesh. The number of meshes for screening and removing impurities of sesame is usually about 20 mesh;

Sieve box: The main structure provides a fixed space for the sesame that needs to be sieved. Sesame Sieving Machine is usually a single sieve box;

Dust cover: reduce dust pollution and sesame waste;

Material inlet and outlet: can automatically feed and discharge materials to achieve fully automatic production;

Vibration motor: power source;

Shock-absorbing spring: It plays a shock-absorbing role while transmitting the exciting force to avoid damage to the screen box.


Technical parameters
