Advantages and limitations of Tumbler Screen

Friday February-17 2023  14:53:51

Compared with traditional screening machinery, Tumbler Screen is characterized by the ability to achieve large output and high-efficiency screening of light and fine powder. This article mainly introduces the advantages and limitations of Tumbler Screen:

1. Does not damage the shape of raw materials

Tumbler Screen adopts the design of imitating manual sieving. The running track of the sieving machine is softer, it will not damage the material and is not easy to generate static electricity. It is very friendly to the sieving of materials that are flammable, explosive and prone to static electricity (such as flour, salt, silicon powder, etc.) , rubber, etc.).

2. High screening accuracy, up to 500 mesh

Tumbler Screen materials are screened out in layers in sequence. You can observe the screening of materials through the observation window to avoid screen rupture and blockage. The screen box of Tumbler Screen can be designed with 1-5 layers, which can be accurate to 2-6 levels Separation (up to 500 mesh or 0.028mm).

3. 99% screening efficiency

Compared with traditional screening machines, Tumbler Screen has a larger unit output area (5-10 times that of ordinary screening machines), a maximum output of 60t/h, and higher screening accuracy (93%~95%). The vacuum feeder, feeding station, and feeder in the production line are used to form an automated production line.

4. The life of Tumbler Screen is about 10 times that of traditional screening machine

Tumbler Screen adopts the unique artificial imitation principle and works at low frequency (rotation speed between 180-280), which is more than 10 times the life of traditional screen machines, saving maintenance costs.

5. Low pollution and low noise

Tumbler Screen is a fully enclosed structure, which can effectively block external pollution and avoid the problem of material dust flying and polluting the production site during the screening process. It operates softly and the noise is lower than 75 decibels, which is 1/5 of other screening equipment such as vibrating screens.

Cons of Tumbler Screen:

1. Difficult to clean thoroughly

Tumbler Screen is generally used for sieving fine powders. Fine powders may be hidden in the gaps of the sieving machine, so special attention should be paid to cleaning corners and gaps;

2. High price

Because the Tumbler Screen is relatively new and the manufacturing process is more complicated, the price will be relatively high;

3. Inseparable from the network cleaning device

The materials to be processed are more refined and complex, and special attention needs to be paid to the selection of the net cleaning device.
