How to choose the right Square Tumbler Screen?

Saturday March-11 2023  14:10:48

Square Tumbler Screen is a low-noise and high-precision fine powder sieving machine, suitable for precise large and small particle separation of materials such as granules and powders. Under normal circumstances and according to the rules, the service life of Square Tumbler Screen can reach more than 20 years. But the premise is to choose the most suitable type of Square Tumbler Screen according to the usage of the device before purchasing.

The selection of Square Tumbler Screen has the following points to note:

1. The output of the equipment is the basic condition to determine whether the Square Tumbler Screen is suitable. The output of Square Tumbler Screen is related to the screen area of the machine, the larger the screen area, the higher the output.

2. The final fineness requirement of the product is the key to choose the mesh number of the screen. The final screening accuracy of the screen is affected by the aperture of the screen and the power of the motor. Therefore, before selecting and confirming the condition of the screen, it is necessary to provide the relevant product production requirements to the manufacturer.

3. The characteristics of the material to be processed determine the material selection of the Square Tumbler Screen. Commonly used materials can be divided into Q235 carbon steel and 304 stainless steel. If the material to be processed is corroded or has high hygiene requirements, please choose stainless steel, which will cost a higher cost accordingly.

4. The damping spring is not only connected to the screen frame and base, but also plays the role of reducing resonance and buffering. Commonly used vibration springs are made of steel springs, and there are composite springs and rubber springs according to the type of equipment.

5. The sealing strip can play the role of sealing and buffering the upper and lower screen frames. Silicone rubber strips are now commonly used, and the specifications of the sealing strips are also different. Therefore, please purchase according to the diameter of the screen frame when purchasing.

6. Whether the installation position of the motor is reasonable will also affect the processing effect of the material. The height of the equipment and the actual placement location can be determined, and motors with special functions such as explosion-proof and waterproof can be selected according to the material characteristics.

If you have a special material or have any other questions, you can directly contact the manufacturer!
