FEATURES

Improve your product purity

Eliminate oversized material from your powders and liquid

Increase your production

These vibratory screen achieve a higher throughput per unit mesh area compared to conventional vibrating screens

Reduce your down-time

Can be easily stripped down and cleaned without tools

Eliminate dust and fumes

Enclosed screening means total containment

Fits into smaller spaces

These vibrating screens can fit easily into existing installations and areas of limited headroom

Lowers noise levels

A solid rubber suspension gives the machine a quiet operation - typically as low as 70dBA

SELECTION

Properties of the powder materials, such as powder density

Demands on the screening accuracy and performance

Throughput

Possible installation mass

Product to screen



APPLICATION

for exmaple:

soybean     sugar powder iron powder
plastic fertilizer paints
starch tablets sandstone



Technical parameters

Technical parameters are provided below! Customization services are also ready for you to contact.

Model Diameter mm Screen area m Screen size(mesh) Feeding granularity mm
DH-600 Φ600 0.24 2-500 <Φ10
DH-800 Φ800 0.45 2-500 <Φ15
DH-1000 Φ1000 0.67 2-500 <Φ20
DH-1200 Φ1200 1.0 2-500 <Φ30
DH-1500 Φ1500 1.6 2-500 <Φ30
DH-1800 Φ1800 2.43 2-500 <Φ30
DH-2000 Φ2000 3.01 2-500 <Φ30
